HOW TO ORDER SUPERIOR GRADE MULTI-BOX PARTS AND ACCESSORIES

PENTAGON WRENCH = PW RISERS = RAISES BOX 1½" - STACKABLE
RIG4 (Compatible with All 4" Valve Boxes)

RIG6 (Used on 6" Heavy Duty Locking Lid)
RIG6N (Used on 6" Heavy Duty Non-Locking Lid)
EXTENSIONS = XTG & One Code from the Following Categories:

     ONE = SIZE                 TWO = LENGTH
            4 = 4"                         AL = 18"
            6 = 6"                         BL = 35 ⅝"  (Not Valid with XTG6)
REPLACEMENT LIDS = LI & One Code from the Following Categories:

ONE = LETTERING       TWO = SIZE            THREE = BOX TYPE                       FOUR = LID TYPE
 G  = Gas                                  4 = 4"                          V = Valve Box                             (Locking is Standard)
S  = Sewer                               6 = 6"                         H = Heavy Duty                             N = Non-Locking
W = Water
D = Drip

FIVE = COLOR                                    SIX = VENT HOLE
(Silver  is Standard)                              C = One 3/8" Vent Hole
A = Yellow
B = Blue
J  = Black
REPLACEMENT UPPER TUBES = UTG & One Code from the Following Categories:

 ONE = BOX SIZE    TWO = BOX TYPE    THREE = BELL DESIGN        FOUR = LENGTH      FIVE = MAGNET
        4 = 4"                      V = Valve Box             C = 'C' Model  Multi-Box         A = 10" (2' Box)           (One Magnet Located in
        6 = 6"                      H = Heavy Duty         T = 'T' Model  Multi-Box         B = 17½" (3' Box)        the Flange is Standard)
                                                                                                                                  C = 21½" (4' Box)         D = No Magnet
                                                                                                                                  D = 29½" (5' Box)        (Heavy Duty Boxes are not
                                                                                                                                                                         supplied with a magnet.)
REPLACEMENT UPPER TUBE & LID ASSEMBLIES - All assemblies begin with UL.  Repeat all the steps beginning with  Category One for REPLACEMENT LIDS and REPLACEMENT UPPER TUBES.
REPLACEMENT LOWER TUBES = LTG & One Code from the Following Categories:

ONE  = BOX SIZE         TWO = ARCH            THREE = BELL DESIGN                        FOUR = LENGTH
       4 = 4"                                A = Yes                    C = 'C' Model Multi-Box                        A = 22⅝"  (2' Box)
       6 = 6"                                N = No                      T = 'T' Model Multi-Box                        B = 27⅛"   (3' Box)
                                                                                                                                                       C = 35⅛"   (4' Box)
                                                                                                                                                       D = 39⅛"   (5' Box)

FIVE = SUPPORT SYSTEM MODIFICATION



FOR OTHER OPTIONS OR VARIATIONS, PLEASE CONSULT THE FACTORY.
