HOW TO ORDER SUPERIOR GRADE BELL PLATE VALVE BOX
PARTS AND ACCESSORIES

PENTAGON WRENCH CODE    =   PW

EXTENSIONS (4") = XTG4 & ONE CODE AL = 18"               BL=35 ⅝" EXTENSIONS (6") = XTG6 & ONE CODE AL=18"

RISERS = RAISES BOX 1½" - STACKABLE RIG4 (Compatible with All 4" Valve Boxes) RIG6 (Used on 6" Heavy Duty Locking Lid) RIG6N (Used on 6" Heavy Duty Non-Locking Lid)

REPLACEMENT LIDS
    LI & One Code from the Following Categories:

ONE = LETTERING TWO = SIZE THREE = BOX TYPE FOUR = LID TYPE FIVE = COLOR SIX = VENT HOLE
                                                                     (Omit Code on 4" Lids)   (Locking is Standard)   (Silver is Standard)
G = Gas                           4 = 4"                   V = Valve Box                   N = Non-Locking         A = Yellow                    C = One 3/8" Vent Hole
S = Sewer                       6 = 6"                   H = Heavy Duty                                                       B = Blue
W = Water                                                                                                                                      J  = Black

REPLACEMENT UPPER TUBES
    4" Models Begin with UTG4 & One Code from the Following Categories:
    6" Models Begin with UTG6 & One Code from the Following Categories:

ONE = BOX TYPE TWO = LENGTH THREE = MAGNET
V = Valve Box                                 A = 10"    (2' Box)             (One Magnet Located in the Flange is Standard)
H = Heavy Duty                             B = 17½" (3' Box)                     D = No Magnet
C = 21½" (4' Box) (Heavy Duty Boxes are not supplied with a magnet.)
D = 29½" (5' Box)

REPLACEMENT UPPER TUBE & LID ASSEMBLIES - All Assemblies begin with UL.  Repeat all the steps beginning with Group One for REPLACEMENT LIDS and REPLACEMENT UPPER TUBES.

REPLACEMENT LOWER TUBES
    4" Models Begin with LTG4N & One Code from the Following Categories:
6" Models Begin with LTG6N & One Code from the Following Categories:

ONE = BELL DESIGN TWO = LENGTH ACCORDING TO THE BELL DESIGN
C = 'C' Model Multi-Box A = 22⅝"   (2' Box)
T = 'T' Model Multi-Box B  = 27⅛"    (3' Box)
                                                                               C = 35⅛"     (4' Box)
                                                                               D = 39⅛"    (5' Box)

THREE = SUPPORT SYSTEM MODIFICATION

FOR OTHER OPTIONS OR VARIATIONS, PLEASE CONSULT THE FACTORY.
