ONE = LID LETTERING
G = Gas
S = Sewer
W = Water

TWO = BOX SIZE
4 = 4"
6 = 6"

THREE = BOX TYPE
V = Valve Box
H = Heavy Duty Box

FOUR = ARCH
N = No

FIVE = LOWER TUBE DESIGN (Skip GROUP FIVE if using GROUP TWO - CODE 4)
C = 'C' Model Multi-Box
T = 'T' Model Multi-Box

SIX = ADJUSTABLE RANGE
(Measured from top of the box to the bottom of the box.  Make your selection from the group that matches your Box Type for Category Three.)

                    VALVE BOXES                                                                               HEAVY DUTY BOXES
                        2 = 24" - 30"                                                                                            2 = 26" - 32"
                        3 = 29" - 42"                                                                                            3 = 31" - 44"
                        4 = 37" - 54"                                                                                            4 = 39" - 56"
                        5 = 41" - 66"                                                                                            5 = 43" - 68"

SEVEN = LID TYPE
(Locking Lid is Standard)
N = Non-Locking

EIGHT = SUPPORT SYSTEM MODIFICATION
If you are using a support with your Valve Box, one of the following codes is required:

NINE = LID COLOR
(Silver is Standard)
A = Yellow
B = Blue
J = Black

TEN = VENT HOLE
C = One 3/8" Vent Hole

ELEVEN = MAGNET
(One Magnet Located in the Flange is Standard)
D = No Magnet   (Heavy Duty Boxes are not supplied with a magnet.)
