HOW TO ORDER SUPERIOR GRADE
6" VALVE BOX PARTS AND ACCESSORIES

PENTAGON WRENCH = PW EXTENSIONS = XTG6 & One Code
AL = 18"               		 RISERS (Raises Box 1½" Stackable)
RIG6 (Used on Heavy Duty Locking Lid)
RIG6N ( Used on Heavy Duty Non-Locking Lid)
REPLACEMENT LIDS = LI & One Code from the Following Categories:

ONE = LETTERING       TWO = SIZE            THREE = BOX TYPE                       FOUR = LID TYPE
 G  = Gas                                  6 = 6"                          V = Valve Box                             (Locking is Standard)
S  = Sewer                                                                  H = Heavy Duty                             N = Non-Locking
W = Water
D = Drip
FIVE = COLOR                                    SIX = VENT HOLE
(Silver  is Standard)                              C = One 3/8" Vent Hole
A = Yellow
B = Blue
J  = Black
REPLACEMENT UPPER TUBES = UTG6 & One Code from the Following Categories:

ONE = BOX TYPE        TWO = LENGTH              THREE = FLANGE           FOUR = MAGNET
V = Valve Box                 A = 10" (2' Box)                  (Locking is Standard)      (One Magnet Located in the Flange is Standard)
H =Heavy Duty              B = 17½" (3' Box)               N = Non-Locking              D = No Magnet
                                          C = 21½" (4' Box)                                                    (Heavy Duty Boxes are not supplied with a magnet.)
                                          D = 29½" (5' Box)
REPLACEMENT UPPER TUBE & LID ASSEMBLIES - All assemblies begin with UL.  Repeat all the steps beginning with  Group One for REPLACEMENT LIDS and REPLACEMENT UPPER TUBES.
REPLACEMENT LOWER TUBES = LTG6 & One Code from the Following Categories:

ONE = ARCH            TWO = BELL DESIGN                THREE = LENGTH ACCORDING TO THE BELL DESIGN
A = Yes                       S = 6" Straight Bell                             CODE(S)                   CODE(B)                 CODE(X)
N = No                        B = 9" Bell                                       A = 23½"(2' Box)      A = 22⅝" (2' Box)     A = 25" (2' Box)
                                    X = 12" Bell                                      B = 28"    (3' Box)     B  = 27⅛" (3' Box)     B  = 31" (3' Box)
                                                                                               C = 36"    (4' Box)      C = 35⅛" (4' Box)     C  = 40" (4' Box)
                                                                                               D = 40"    (5' Box)     D = 39⅛" (5' Box)     D  = 53" (5' Box)

FOUR = SUPPORT SYSTEM MODIFICATION

FOR OTHER OPTIONS OR VARIATIONS, PLEASE CONSULT THE FACTORY.
